UNITE® 150 PTZ HD CAMERA

With Aura, Professionals can now Re-imagine their Workspaces at Home

UNITE® 150 PTZ Camera
  • Full-HD 1080p30 video and 12x optical zoom for high video quality, regardless of where the camera is installed in your professional home office.
  • Compatible with popular applications such as COLLABORATE® Space, Microsoft® Teams, WebEx™ Zoom™, Google® Meet™, and more.
  • Control the camera’s functions via IR remote, RS-232, or UVC protocol.
  • FREE COLLABORATE® Space lifetime subscription — ClearOne’s high quality, award winning cloud-based video collaboration application.
  • Super-high SNR with advanced 2D and 3D noise reduction.
  • Transforms any meeting room into a professional grade video collaboration room.
  • Simple USB 3.0/2.0 compatibility with UVC and UAC protocol support.

  • AUR-2100-004 UNITE® 150 USB PTZ Camera

INCLUDES

VIDEO

  • VIDEO FORMATS: 1080p30, 1080p25, 720p30, 720p25
  • Sensor: 1/2.7 inch, CMOS
  • Effective pixel: 2.07M
  • Scanning mode: Progressive
  • Lens : 12x, f3.5 mm – 42.3 mm, f1.8 – f2.8
  • Focus mode : Auto Focus
  • Minimal illumination: 0.5 lux @ (f1.8, AGC ON)
  • Shutter: 1/30 S – 1/10000 S
  • White balance: Auto , Indoor, Outdoor, One Push, Manual
  • Backlight compensation: Supported
  • Digital Noise Reduction: 2D & 3D
  • Video S/N: ≥55dB
  • Horizontal angle of view: 72.5° – 6.9°
  • Vertical angle of view: 44.8° – 3.9°
  • Horizontal rotation range: ±170°
  • Vertical rotation range: -30° – +90°
  • Pan speed range: 1.7° – 100°/S
  • Tilt speed range: 1.7° – 69.9°/S
  • H & V FLIP: Supported
  • Image freezing: Supported
  • Number of presets: 255
  • Installation: Stand Mount, upside-down mount

INPUT/OUTPUT INTERFACE

  • Audio interface: 1-CH 3.5MM Audio Interface, Line In
  • USB interface: 1 x USB3.0: type B Female jack
  • Communication: 1 x Rs-232 in : 8-Pin Min din, Max distance: 30 m, Protocols: VISCA/Pelco-D/Pelco-P
  • 1x RS-232 Out: 8-Pin Min din, Max distance: 30 M, Protocols: visca network use Only

COMPATIBILITY

  • Operating Systems: Windows 7, Windows 8, Windows 8.1, Windows 10, MAC OS, Linux
  • Color System: YUV 4:2:2
  • USB 2.0: 720P30 maximum
  • NOTE: Use of USB 2.0 downgrades video quality. ClearOne does not recommend using USB 2.0 extenders.
  • USB Video Communication: UVC 1.0 - UVC 1.5
  • Audio on USB: Supported
  • UVC PTZ: Supported

POWER

  • Power jack: JEITA type (DC In 12 V)
  • Input voltage: DC 12 V
  • Current consumption: 1.0 A (max)
  • Power consumption: 12 W (max)

ENVIRONMENTAL

  • Operating temperature: +14° F–104° F (-10° C – 40° C)
  • Storage temperature: -40° F – 140° F (-40° C – 60° C)
  • MTBF: >30000h

MECHANICAL

  • Dimensions (W x D x H): 5.67 x 5.67 x 6.61” (144 x 144 x 168mm)
  • Weight: 2.0lb (0.91kg)
