NFC Tap-to-Pair allows fast and simple connectivity with mobile devices.

Key Highlights

  • Bluetooth pair name can be customized.
  • P-Link* makes wiring easy on both CP2 and Huddle systems.
  • Wall-mount design for convenient room access (single-gang electrical box).
  • Bluetooth 3.0 compliant interface supports industry standard profiles for audio.
  • Has great range – up to 150 feet (45 meters).

Applications

  • Audio Conferencing
  • Video Conferencing
  • BYOD Conferencing
  • Web conferencing

Workspaces

  • Executive Offices
  • Huddle Spaces
  • Conference Rooms
  • Multi-purpose Rooms
  • Boardrooms
  • Lecture Halls

NFC Tap-to-Pair allows fast and simple connectivity with mobile devices.

BLUETOOTH WIRELESS TECHNOLOGY

  • • Version: 3.0
    • Mode: Bluetooth Classic
    • Supported Profiles
    • Hands-Free Profile v.1.6 (HFP)
    • Distribution Profiles v.1.5 (A2DP, AVRCP)
    • Supported Codec
    • Default SBC (44.1kHz) do not list on datasheet, other upon request. Hands-Free Profile v.1.6 (HFP)
    • Wireless Performance
    • Frequency Band: 2390 MHz to 2483.5MHz
    • Transmit Power: +6.5dBm
    • Receiver Sensitivity: -90dBm3
    • Wireless Range: Up to 150 feet (45 meters)

INDICATORS AND MOMENTARY SWITCH

  • • LED
    • Blinking Blue - Ready to Pair
    • Solid Blue - Paired
    • Toggle Switch
    • Press to reset Bluetooth - break Bluetooth connection and set into pairing mode.

P-LINK IN (PROPRIETARY NETWORK)

  • • RJ45: Cat5e, Cat6, P-Link In only
    • Cable Length: 200ft (test up to 250 ft)

POWER CONSUMPTION

  • • P-Link In, RJ45
    • 2.24 Watt

THERMAL

  • • 7.64 BTU/Hr

OPERATING TEMPERATURE

  • • 14°F/-10°C to 104°F/40°C

DIMENSIONS

  • • 1.7” x 4.4” x 1.6” (44 mm x 112.5mm x 40mm)

WEIGHT

  • • Product weight: .19 lbs (88g)
    • Shipping weight: .35 lbs (.16kg)

COMPLIANCE

  • • This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference.
    • FCC ID: QOQWT32I
    • IC: 5123A-BGTWT32I
    • MIC ID: 209-J00089
    • KCC: MSIP-CRM-BGT-WT32i

PART NUMBER

  • • 910-3200-303
