Key Highlights

  • Full HD 1080p60 video, 20x optical zoom plus 16x digital zoom, and capability to capture all participants in the room.
  • The use of advanced focusing algorithms enables the lens to focus quickly, accurately, and steadily.
  • Control the camera’s functions via USB network, RS485 and RS232 interfaces to control the camera.
  • H.264/H.265 streaming and line-in interface to stream audio and video over IP.
  • High SNR of CMOS sensor combined with 2D and 3D noise reduction algorithm, effectively reduces the noise, even under low illumination conditions. Image can still keep clean and clear.
  • Includes local storage to directly record without the need for external NVR.
  • Supports PoE.
  • Supports USB 3.0 and 2.0 interfaces. The USB interface supports YUY2, MJPEG and H.264 video formats.
  • Compatible with popular applications such as Microsoft®Teams, Zoom™, GoToMeeting™, WebEx™, ClearOne’s COLLABORATE® Space, and more.

APPLICATIONS

  • Web Conferencing
  • Unified Communications

WORKSPACES

  • Large Conference Rooms
  • Training Centers
  • Classrooms

CAMERA

  • Video System:
    • HD: 1080p60
    • 1080p50
    • 1080i60
    • 1080i50
    • 1080p30
    • 1080p25
    • 720p60
    • 720p50
    • 720p30
    • 720p25

SENSOR

  • 1/2.8 inch, CMOS
  • Effective Pixel: 2.07M
  • Scanning Mode: Progressive
  • Lens: 20x, f4.4mm – 88.5mm, f1.8 – f2.8
  • Optical Zoom: 20x
  • Digital Zoom: 16x
  • Focus Mode: Auto Focus
  • Minimal Illumination: 0.5 l ux @ (f1.8, Agc ON)
  • Shutter: 1/30s – 1/10000s
  • White Balance: Auto, Indoor, Outdoor, One Push, Manual
  • Backlight Compensation: Supported
  • Digital Noise Reduction: 2D & 3D Digital Noise Reduction
  • Video S/N: ≥55dB
  • Horizontal Angle of View: 60.7° – 3.36°
  • Vertical Angle of View: 34.1° – 1.89°
  • Horizontal Rotation Range: ±170°
  • Vertical Rotation Range: -30° – +90°
  • Pan Speed Range: 1.7° – 100°/S
  • Tilt Speed Range: 1.7° – 69.9°/S
  • H & V FLIP: Supported
  • Image Freezing: Supported
  • Local Storage: Supported
  • Number of Presets: 255
  • Preset Accuracy: 0.1°
  • Flexible Installation: Stand mount, Upside-down mount

INPUT/OUTPUT INTERFACE

  • HD Output: 1 x HDMI: Version 1.3
  • Network Interface: 1 x RJ45: 10M/100M Ethernet Interface
  • Audio Interface:
    • 1-Ch 3.5mm Audio Interface, Line In
    • 1-Ch 3.5mm Audio Interface, Mic In
    • 1-Ch 3.5mm Audio Interface, Line Out
  • USB: 1 x USB 3.0: type B female jack, 1 x USB 2.0: type A female jack
  • Communication: 1 x RS232 In: 8-Pin Min din, Max distance: 30M, Protocols: VISCA/Pelco-D/Pelco-P 1 x RS232 Out: 8-Pin Min din, Max distance: 30M, Protocols: VISCA network use Only, 1 x RS485: Share with RS232 Out, Max distance: 1200M, Protocols: VISCA/Pelco-D/Pelco-P

    USB FEATURES

    • Operating Systems: Windows 7, Windows 8, Windows 10, MacOS X, Linux
    • Color System: YUY2/MJPEG/H.264
    • Video Formats:
      • USB 3.0:
        • 1080p60
        • 1080p50
        • 1080p30
        • 1080p25
        • 720p60
        • 720p50
        • 720p30
        • 720p25
      • USB 2.0:
        • 960x540p/30
        • 960x540p/25
        • 640x360p/60
        • 640x360p/50
    • USB Video Communication: UVC 1.1
    • UVC PTZ: Supported

    IPC FEATURES

    • Video Compression: H.265/H.264/MJEPG
    • Video Stream: Main Stream, Sub Stream
    • Main Stream Resolution: 1920x1080, 1280x720, 1024x576
    • Sub Stream Resolution: 720x576, 720x480, 320x240
    • Video Bit Rate: 128Kbps - 8192Kbps
    • Bit Rate Type: Variable Rate, Fixed Rate
    • Frame Rate: 50Hz: 1fps - 50fps, 60Hz: 1fps - 60fps
    • Audio Compression: AAC
    • Audio Bit Rate: 96Kbps, 128Kbps, 256Kbps
    • Support Protocols: TCP/IP, HTTP, RTSP, RTMP, Onvif, DHCP, Multicast, etc

    GENERIC SPECIFICATIONS

    • Power Jack: JEITA type (DC In 12V)
    • Input Voltage: DC 12V
    • Current Consumption: 1.0A (Max)
    • Power Consumption: 12W (Max)
    • Operating Temperature: -10°c – 40°c (14°F - 104°F)
    • Storage Temperature: -40°c – 60°c (-40°F - 140°F)
    • Dimension: 240mm x 144mm x 160mm
    • Weight: 1.65 kgs (3.6 lb)

    OPTIONAL ACCESSORIES

    • 910-2100-103: Wall Mount for UNITE 200 Camera
    • 910-2100-203: Ceiling Mount for UNITE 200 Camera
    • 910-2100-002: USB 3.0 Cable

    PART NUMBER

    • 910-2100-080
