Key Highlights

  • Full HD 1080p30 video, 12x optical zoom, and capability to capture all participants in the room
  • Compatible with popular applications such as COLLABORATE® Space, Microsoft® Teams, WebEx™, Zoom™, GoToMeeting™, and more
  • Control the camera’s functions via IR remote, RS-232, or UVC protocol.
  • Transforms any meeting room into a professional-grade video collaboration room
  • Super-high SNR with advanced 2D and 3D noise reduction
  • Simple USB 3.0/2.0 compatibility with UVC and UAC protocol support.

Applications

  • PC-based video conferencing
  • Web conferencing
  • Unified communications
  • Capture applications and more

Environments

  • Huddle spaces
  • Executive offices
  • Conference rooms
  • Boardrooms
  • Training centers

CAMERA

  • Video System:
    • HD: 1080p30
    • 1080p25
    • 720p30
    • 720p25
  • Sensor: 1/2.7 inch, CMOS
  • Effective Pixel: 2.07M
  • Scanning Mode: Progressive
  • Lens : 12x, f3.5MM – 42.3MM, f1.8 – f2.8
  • Focus Mode: Auto Focus
  • Minimal Illumination : 0.5 l ux @ (f1.8, Agc On)
  • Shutter : 1/30S – 1/10000S
  • White Balance : Auto , Indoor, Outdoor, One Push, Manual
  • Backlight Compensation : Supported
  • Digital Noise Reduction : 2D & 3D Digital Noise Reduction
  • Video S/N : ≥55dB
  • Horizontal Angle of View : 72.5° – 6.9°
  • Vertical Angle of View : 44.8° – 3.9°
  • Horizontal Rotation Range : ±170°
  • Vertical Rotation Range : -30° – +90°
  • Pan Speed Range : 1.7° – 100°/S
  • Tilt Speed Range : 1.7° – 69.9°/S
  • H & V FLIP : Supported
  • Image Freezing : Supported
  • Number of Presets : 255
  • Flexible Installation : Stand Mount, upside-down mount

Input/Output Interface

  • Audio Interface : 1-CH 3.5MM Audio Interface, Line In
  • USB Interface : 1 x USB3.0: type B Female jack
  • Communication : 1 x Rs-232 in : 8-Pin Min din, Max distance: 30m, Protocols: VISCA/Pelco-D/Pelco-P
  • 1x RS-232 Out : 8-Pin Min din, Max distance: 30M, Protocols: visca network use Only

USB FEATURES

  • Operating Systems: Windows 7, Windows 8, Window 8.1, Windows 10, MacOS, Linux
  • Color System: YUV 4:2:2
  • Video Formats:
    • USB3.0: 1080p30
    • 1080p25
    • 720p30
    • 720p25
  • USB 2.0: 720P30 maximum
  • NOTE:Due to limitations with USB 2.0, video quality would be downgraded. USB 2.0 extenders are not recommended.
  • USB Video Communication: UVC 1.0 - UVC 1.5
  • Audio on USB: Supported
  • UVC PTZ: Supported

GENERIC SPECIFICATIONS

  • Power Jack : Jeita Type (DC in 12v)
  • Input Voltage : DC 12v
  • Current Consumption : 1.0A (MAX)
  • Power Consumption: 12w (max)
  • Operating Temperature True : -14°F–104°F (-10°C – 40°C)
  • Storage Temperature : -40°F – 140°F (-40°C – 60°C)
  • MTBF: >30000h
  • Dimension : : 5.67” x 5.67” x 6.61” (144mm x 144mm x 168mm)
  • Weight : 2.0lb (0.91Kg)

OPTIONAL ACCESSORIES

  • 910-2100-104: Wall Mount for UNITE 150 Camera
  • 910-2100-204: Ceiling Mount for UNITE 150 Camera
  • 910-2100-002: USB 3.0 cable

PART NUMBER

  • 910-2100-004
