  • Enables Unified Communication in the conference room
  • USB port connects to PC for Skype, WebEx and other A/V conferencing applications
  • Headset port connects to Cisco, Avaya, and Nortel handsets
  • Sound quality exceeds traditional conference phone with ClearOne’s HDConference technology
    • Simplified installation combines all microphone signals onto a single data cable minimizing conduit and raceway requirements.
    • Noise cancellation reduces background noises from fans or HVAC systems
    • Automatic level controls keep participants’ audio balanced and consistent
  • Scalable and flexable
    • Multiple speaker mount options: wall, ceiling or custom
    • Select appropriate number of MIC EX and MIC PODS (max three) to fit the applications
  • Integral network management system enables remote configuration, control and monitoring
  • Interoperates with NetStreams® A/V over IP systems
  • Easy to install, program and use

AUDIO PERFORMANCE

  • Conditions: Unless otherwise specified, all
  • measurements are performed from 20 Hz to
  • 15 kHz BW limit (No Weighting)
  • Dynamic Range:
    • 80 dB (Non-A Weighted) THD+N: < 0.02%

AUDIO MIXER

  • AEC Tail Time: 128 ms
  • Adaptive Noise Cancellation: 6-15 dB
  • Gating: Adaptive Ambient, 1st Mic Priority, Lookahead Gating
  • Up to a total of 3 INTERACT MIC or INTERACT
  • MIC EX devices can be connected to the
  • INTERACT AT Mixer
  • 48 kHz Sample Rate, 24-bit Resolution

AUDIO MIXER LINE INPUT

  • Connection: Unbalanced RCA
  • Impedance: 10 kΩ
  • Nominal Level: -10 dBu
  • Maximum Level: +9 dBu

AUDIO MIXER PLAYBACK

  • Connection: Unbalanced Left and Right RCA
  • (Summed Internally)
  • Impedance: 10 kΩ
  • Nominal Level: -10 dBu
  • Maximum Level: +15 dBu

AUDIO MIXER LINE OUTPUT

  • Connection: Unbalanced RCA
  • Impedance: 10 kΩ
  • Nominal Level: -10 dBu
  • Maximum Level: +9 dBu

AUDIO MIXER RECORD OUTPUT

  • Connection: Unbalanced Left and Right RCA (Mono Source Split Internally)
  • Impedance: 10 kΩ
  • Nominal Level: -10 dBu
  • Maximum Level: +9 dBu

AUDIO MIXER AMPLIFIER OUTPUT

  • Connection: Left and Right Push Terminals
  • Power: 5 Watts
  • Frequency Response: 20 Hz – 15 kHz (+/-1 dB)
  • Dynamic Range:
    • 80 dB THD+N: < 0.50% (+5 dBu Line Input @ 1 kHz)

TELEPHONE INTERFACE

Telephone Audio Performance

  • Conditions: Unless otherwise specified, all
  • measurements are performed with Transmit
  • Limiter and Receive ALC disabled

Frequency Response:

  • 250 Hz to 3.3 kHz ±1 dB THD+N: < 0.30%
  • re-max level 250 Hz to 3.3 kHz
  • SNR: > 62 dB re-max level

Telco Line Echo Cancellation

  • Tail Time: 32 ms
  • Null: 55 dB Nominal

Telephone Noise Cancellation

  • Noise Cancellation 6-15 dB Attenuation

RS-232 CONTROL PORT

  • DB9 Female
  • Baud Rates: 9,600 / 19,200 / 38,400 /
  • 57,600 (Default) / 115,200
  • Protocol: 8 Bit / 1 Stop / No Parity
  • Hardware Flow Control ON (Default)/OFF

USB CONFIGURATION PORT

  • USB 2.0 Compatible
  • Type: B Connector

VISCA CAMERA PORT

  • Din, 9600 Baud, No Flow Control

LAN

  • 10/100 Ethernet
  • RJ-45 with Activity LED
  • Supports: Telnet, HTTP

LINK BUS

  • Connection: RJ-45 with CAT5 Daisy-chained
  • Maximum Distance: 60 feet from Mixer to last device in chain
  • Maximum Number of INTERACT MIC Devices: 3 - Any Mix of INTERACT MIC or MIC EX
  • Maximum Number of INTERACT COM Devices: 1 per INTERACT Mixer

CONFIGURATION SOFTWARE

  • INTERACT Supports:
  • Microsoft XP, Vista and Windows 7

INTERACT COM

USB AUDIO CHANNEL:

  • USB 2.0 Compatible
  • Connector: Mini Type B
  • TX and RX Channel, 16-bit at 16 kHz

HEADSET AUDIO CHANNEL:

  • Connector: RJ-9

Supported Telephone Sets:

  • Most Cisco, Avaya, and Nortel Phones

Audio Performance

  • Frequency Response: 40 to 3300 Hz
  • THD and Noise: < 0.04% re-max level with
  • 0 dB Gain @ 1 kHz
  • Dynamic Range: > 84 dB (Non A-Weighted)

Audio Processing:

  • Receive Automatic Level Control
  • Line Echo Cancellation for Side-Tone
  • Elimination

GPIO:

  • Pin 1: Global Mute (C)
  • Pin 2: Global Mute (S)
  • Pin 3: ON/OFF Hook (C)
  • Pin 4: ON/OFF Hook (S)
  • Pin 5: 5V DC up to 40 mA

INTERACT MIC – TABLETOP MICROPHONE

  • Coverage: 360°
  • Frequency Response: 60 Hz - 14 kHz THD+N: < 0.08% (-45 dBu Input @ 1 kHz)
  • Sensitivity: -45 dBu

INTERACT MIC EX - MICROPHONE

DISTRIBUTION BOX

  • Connection: Female XLR Balanced
  • Maximum Level :+18 dBu
  • Frequency Response:
  • 20 Hz – 15 kHz THD + N: < 0.01%
  • Phantom Power: 24 V @ 10 mA
  • Impedance: 5 kΩ per Leg or 10 kΩ Balanced

POWER SUPPLY

  • Primary Voltage: 100 to 240 VAC
  • Auto-Sensing, 50-60 Hz
  • Power Consumption: 32 W Maximum

DIMENSIONS (W X D X H)

  • INTERACT AT Mixer: 17” x 7.5” x 2” (43.2 cm x 19.1 cm x 5.1 cm)
  •  INTERACT MIC EX: 4.7” x 5.6” x 1.7” (11.9 cm x 14.3 cm x 4.4 cm)
  • INTERACT COM: 4.7” x 5.6” x 1.7” (11.9 cm x 14.3 cm x 4.4 cm)
  • INTERACT MIC: Diameter: 7” (17.8 cm)
  • Height: 1.5” (3.8 cm)

WEIGHT

  • INTERACT AT Mixer: 4.5 lbs. (2.25 kg)
  • INTERACT MIC: 1.5 lbs. (0.75 kg)
  • INTERACT MIC EX: 1.5 lbs. (0.75 kg)
  • INTERACT COM: 1.5 lbs. (0.75 kg)

COMPLIANCE

  • ROHS Compliant
  • WEEE Compliant
  • UL Safety Listed
  • AES48-2005 AES Standard on Grounding and
  • EMC Practice

PART NUMBERS

  • Complete Room Solutions:
  • Call ClearOne for complete listing of room options.
  • INTERACT AT: 910-154-010
  • INTERACT COM: 910-154-030
  • INTERACT MIC: 910-154-015
  • INTERACT MIC EX: 910-154-020
  • ClearOne Wall Speaker: 910-151-002-01
  • ClearOne Ceiling Speaker: 910-151-001-01
