Surpasses any other professional digital wireless product for reliability, features, and value.

Key Highlights

  • Robust solution containing four different types of mic transmitters, charging dock, and spatial-diversity antenna distribution system.
  • Single WS800 system covers up to six rooms; lowering equipment costs and allowing rooms to share microphones.
  • Free design and commissioning services expedite the design of simple or complex projects.
  • Wide audio bandwidth provides superior speech clarity, and low audio latency enables effective AEC processing.
  • Includes eight 32-channel global RF bands, with multiple bands per region, for more potential available mic channels than single-band DECT systems.
  • The most options for transmitter powering and charging of any wireless system.
  • Easily scalable with 4 or 8 channels per RU
  • Fits more project budgets than competing systems, with aggressive MSRP and dealer pricing.
  • Highly secure; using “always-on” AES256 encryption.
  • Works seamlessly with ClearOne audio & video solutions; and easily integrated with other 3rd-party sytems.
  • Simple configuration and management through the full-featured software.
  • Includes an industry-leading, 3-year warranty.
  • Flexible pick-up pattern and capsule options to support a wide range of applications.

Applications

  • Audio conferencing
  • Video collaboration
  • Sound reinforcement

Workspaces

  • Huddle spaces
  • Conference rooms
  • Boardrooms
  • Training rooms
  • Lecture Halls
  • Courtrooms
  • Telemedicine theatres

Surpasses any other professional digital wireless product for reliability, features, and value.

WS800 Wireless Microphone System

  • Wireless System: Up to 24-bit, 48 KHz, digital audio RF technology
  • Channels: 4 or 8-channel receivers
  • Daisy-chainable up to 32 channels per RF band
  • RF Range:
    - M500: 486 MHz to 512 MHz
    - M550: 537 MHz to 563 MHz
    - M586: 573 MHz to 599 MHz
    - M610: 605 MHz to 632 MHz
    - M715: 712 MHz to 737 MHz
    - M800: 793 MHz to 819 MHz
    - M915: 902 MHz to 928 MHz
    - M930: 917 MHz to 943 MHz
  • Working Range: 300 feet (line-of-sight)
  • Encryption: 256 bit key (AES) always-on, laboratory-verified | NSA FIPS 197 standard
  • Frequency Response: 16 channels 20 Hz - 20 KHz (stage) | 32 channels 20 Hz - 20 KHz (compressed, conference) | 32 channels 20 Hz - 12 KHz (non-compressed, conference)
  • S/N Ratio: 109 dB (typical ‘A’ weighted)
  • Total Harmonic Distortion: <0.03% @ 1kHz
  • Latency: Stage - 3ms | Conference, non-compressed - 4ms | Conference, compressed - 9 to 10ms
  • Stability: <5ppm
  • Operation Temperature Range: 0 - 50 degrees Celsius ambient temperature

Charging Station (Docking Station)

  • Housing: ABS
  • Capacity : Charges 8 microphones simultaneously (mix and match any type of the supplied microphones)
  • Power: 5.6V DC / 4 A
  • Dimension: 13.25 x 5.75 inches
  • Weight: 1.30 lbs (.58 kg)

Extension Antennas

  • Mount: Wall mount, ceiling or mic-stand mount
  • Connectors : Straight connectors
  • Reception Pattern: 130-degree reception pattern
  • Gain: Provides 15dB of RF gain (915MHz)
  • Power: Phantom-powered from the receiver
  • Dimensions: 5.8”(dia) x 1.125”(d) (14.8cm x 2.9cm)
  • Weight: .55 lbs (.24 kg)

Transmitters (Microphones)

  • Mic Polar Pattern : Cardioid, omni
  • RF Output : 1, 10, 25 or 50mW, user selectable
  • Power: USB or AA rechargeable (included) or AA disposal
  • Antenna: Internal
  • LED Indicators: Battery status, mute status
  • Button: Press to talk, press to mute (or logic mute), toggle on/off
  • Programmable Switch: Talk, mute, logic mute, on / off
  • Frequency Response: 60 - 20kHz (Omni version); 60 - 15kHz (Cardioid version)
  • Signal-to-Noise Ratio: 80dB Typ. at 1kHz (1Pa) ‘A’ weighted (Omni version); 74dB Typ. at 1kHz (1Pa) ‘A’ weighted (Cardioid version)
  • Battery: Two rechargeable NiMH included, standard AA size
  • Battery Charge Time: 4 hrs
  • Battery Talk Time: Up to 8 hrs continuous usage per charge, typical @ 1mW
  • Dimension: 3.9 L x 2.8 W x .69 H inches
  • Weight: 0.25lbs (.12 Kg) including batteries

Gooseneck Microphone

  • Mic Polar Pattern: Cardioid, Super-Cardioid
  • Gooseneck Lengths : 6, 12 or 18 inch, with double bend
  • RF Output: 1, 10, 25 or 50mW, user-selectable
  • Frequency Response: 60 - 15kHz
  • Signal-to-Noise Ratio: 74dB Typ. at 1kHz (1Pa) ‘A’ weighted
  • Antenna: Internal
  • Power: USB or AA rechargeable (included) or AA disposal
  • Button: Press-to-talk, press-to-mute (or logic mute), toggle on/off
  • LED Indicators: Battery status, mute status
  • Programmable Switch: Talk, mute, logic mute, on / off
  • Battery: Four rechargeable NiMH included, standard AA size
  • Battery Charge Time: 4 hrs
  • Battery Talk Time: Up to 16 hrs continuous usage per charge, typical @ 1mW
  • Dimension: 6.1 L x 4.6 W x 1.4 H inches
  • Weight: 1.60lbs (.72 Kg) including batteries

Receiver (Base Station)

  • Channels per receiver: 4-channels (WS840), 8 channels (WS880)
  • Power Requirements : 100-240 VAC 50-60 Hz, 15 Watts
  • Display: OLED
  • External Antennas: Support up to six pairs per system
  • Antenna Distribution: Attach up to 32 channels to one pair of antennas
  • Analog Audio Outputs: Phoenix terminal blocks or with XLR adapters
  • Output Impedance: 100 Ohm
  • Headphone out (mixed): Balanced 1/4 inch TRS mixed line out for recorders or powered speakers; or headphone out
  • Interface: USB, RS232 & Ethernet (dual port 10/100 Mbps)
  • Dante™ Audio channels: Eight (8) digital outputs @ 48 KHz.
  • Dante Ports: Primary & secondary, RJ45 ports, 100/1000 Mbps, 328 ft.
  • GPIO Interface: 22 programmable pins
  • Gain Adjustment Range: -20dB to +31 dB
  • Dimension: 1-U rack-mount, 19 x 1.75 x 6.5 inches
  • Weight: 4.7 lbs (2.14 kg) for 8-channel receiver; 4.5 lbs (2.04 kg) for 4-channel receiver

Handheld Microphone

  • Mic Polar Pattern: Cardioid, Super-Cardioid, or Hyper-Cardioid
  • Frequency Response: 60 - 15kHz
  • Signal-to-Noise Ratio: : 74dB Typ. at 1kHz (1Pa) ‘A’ weighted
  • Antenna: Internal
  • Display: OLED
  • Power: USB or AA rechargeable (included) or AA disposal
  • Indicators: Battery status, mute status
  • Programmable Switch: Talk, mute, logic mute, on / off
  • Battery: Two rechargeable NiMH included, standard AA size
  • Battery Charge Time: 4 hrs
  • Battery Talk Time: Up to 8 hrs continuous usage per charge, typical @ 1mW
  • Dimension: 10.2 L x 1.4 W x 1.4 H inches
  • Weight: 0.75lbs (.34 Kg) including batteries

Beltpack Transmitter

  • RF Output : 1, 10, 25 or 50mW, user-selectable
  • Antenna: External, field-replaceable
  • Display: OLED
  • Power: USB, AA rechargable (included), or AA disposable
  • Indicators: Battery status, mute status
  • Programmable Switch: Talk, mute, logic mute, on / off
  • Mic Input Impedance: 47 K Ohms
  • Mic Bias: 3V
  • Mic Connector: TA4
  • Battery: Two rechargeable NiMH included, standard AA size
  • Battery Charge Time: 4 hrs
  • Dimension: 2.8 L x 2.4 W x .66 H inches
  • Weight: 0.35 lbs (.16 Kg) including batteries

Lavalier Mic for Beltpack Transmitter

  • Mic Polar Pattern: Omni
  • Frequency Response: 20 - 20kHz
  • Signal-to-Noise Ratio: Above 56dB at 1kHz (1Pa) ‘A’ weighted

Headset Mic for Beltpack Transmitter

  • Mic Polar Pattern: Omni
  • Frequency Response: 50 - 18kHz
  • Signal-to-Noise Ratio: Above 56dB at 1kHz (1Pa) ‘A’ weighted
  • Headset: Single-ear headset
