The industry's best processing and security with easy-to-use setup.

Flexible & Scalable

Digital wireless microphone system with different RF ranges, using from 2 to 32 channels, to serve multiple rooms.

Modular & Secured

Field-replaceable components – Receiver, Transmitters, Mic-heads, and Batteries. AES encryption for highly secured wireless audio.

Optimized for DSP

Optimized for ClearOne DSP mixers. Also works with any third-party mixers. WS800 works with Dante products. DIALOG 20 natively connects with CONVERGE Pro 2.

One-stop shop for Mics

ClearOne offers all types of microphones: Beamforming Microphone Array, Ceiling Microphone Array, wireless microphones, or wired tabletop microphones.

Collaboration Suite for Any Need

ANY WORK SPACE • ANY APPLICATION

WS800DIALOG 20
Features
RF RangeBelow 1 GHz range, 7 RF ranges (915 MHz, 930 MHz, 800 MHz, 715 MHz, 610 MHz, 586 MHz, 500 MHz) 2.4 GHz, 1 RF range
Channel FrequencyFixed frequencyFrequency hopping spread spectrum
Number of Channels322
EncryptionAES 256AES 128
Receiver MountRack mountRack, Ceiling, Wall mountable
AntennaLong cable runs via powered antennasShort cables with passive antennas
Network AudioDanteNo (P-link to CONVERGE Pro 2)
Audio outputEuroblock (external adapter for XLR output) XLR (external adapter for Euroblock output)
Mixed audio outputYesYes
Power for ReceiverAC or DC power supplyPoE, Micro-USB or P-Link
Power for TransmittersAA batteries, Micro-USBAA batteries, Micro-USB
Transmitter RF output power1, 10, 25, 50 mW1, 10 mW
PC software for configurationYesYes
PC connectionUSB, IP, RS232Micro-USB
Works with DSPWorks with ClearOne and any 3rd party DSP unitsWorks with ClearOne and any 3rd party DSP units
Native connection to ClearOne DSPNoYes (CONVERGE Pro 2 Mixer & DIALOG 20 Receiver connect through P-link)
Native connection to ClearOne Beamforming Mic Array 2NoYes (Connect through P-link)
