UNITE® 50 4K ePTZ Camera

Combine with your own choice of mic and speaker for an exceptional collaboration experience.

Combine 120 degree field-of-view and digital zoom with your own choice of mic and speaker to enjoy an exceptional collaboration experience.

Key Highlights

  • Ultra HD 4K video, auto-focus, and 3x digital zoom.
  • Super-high SNR with advanced 2D and 3D noise reduction.
  • Full-function USB 3.0 interface for video and power.
  • 120 degree wide-angle field-of-view.
  • Wide dynamic range support for optimal image capture.
  • Control the camera’s functions via IR remote or UVC protocol.
  • Easily mounted on monitors using standard damping rotary-shaft support.
  • Perfect for popular cloud-based applications such as ClearOne’s COLLABORATE® Space, Microsoft Teams and Skype for Business, Zoom, WebEx, GoToMeeting, and others.

Applications

  • BYOD video conferencing
  • Web conferencing
  • Unified communications

Environments

  • Huddle spaces
  • Small meeting rooms
  • Executive offices

Combine 120 degree field-of-view and digital zoom with your own choice of mic and speaker to enjoy an exceptional collaboration experience.

Video System

  • 4K: down-compatible with 1080p30 and 720p.
  • Sensor: 1/2.5’’, CMOS, Effective Pixel: 8.29M
  • Scanning Mode: Progressive
  • Lens: Focus: f=2.8mm, FOV: 120°
  • Minimal Illumination: 0.05 Lux @ (F1.8, AGC ON)
  • Shutter: 1/30s – 1/10000s
  • White Balance: Auto, Indoor, Outdoor, One Push, Manual
  • Backlight Compensation: Supported
  • Digital Noise Reduction: 2D & 3D Digital Noise Reduction
  • Horizontal Angle of View: Wide angle up to 120°
  • Electronic Pan Tilt Zoom
  • Easy Installation: Equipped with damping rotary shaft bracket to fit almost any display, easy to install, stable and reliable.

USB Features

  • Operating Systems: Windows 7, Windows 8, Windows 8.1, Windows 10, MacOS, Linux
  • Video Formats: 4K30, 1080p30, 1080p25, 720p30, 720p25, 960x540p30, 960x540p25, 640x360p30, 640x360p25, etc.
  • USB Video Communication: UVC 1.0/1.1
  • UVC PTZ: Supported

Input/Output Interface

  • USB Interface: 1xUSB 3.0: Type B, female

Generic Specifications

  • Input Voltage: 5v (USB power supply)
  • Current Consumption: 600 mA
  • Power Consumption: 3.0 W
  • Operating Temperature: 14°F ~ 104°F (-10°C ~ 40°C)
  • Storage Temperature: -40°F ~ 140°F (-40°C ~ 60°C)
  • MTBF: >30000 h
  • Dimensions: Weight: 0.34 kg
  • Part Number: 910-2100-004
